DG2160

Broadband CPE – xDSL Gateways

DG2160

DG2160

802.11n/ac Dual Band Gigabit All-In-One VDSL2 Residential Gateway for xDSL Network Operators

DG4010 is a VDSL2 RGW offering speed up to 300Mbit/s by using copper line. Its wired and wireless combined network via VDSL2 and WI-Fi technologies improves home network, and enables operators to provide the quality of video, voice, and data services over DSL line.

Product Map

INQUIRY

For more information, please click here

Click

Features & Differentiators
+ Bonding Technology for Improved Bandwidth
+  All-In-One
    . Wi-Fi 11a/b/g/n/ac 2.4GHz and 5GHz
    . 2 FXS for analog phones and faxes
+  Green Router
    . RF Power Saving
    . One touch WiFi On/Off Button
    . Adaptive CPU and Ethernet power saving
+  Intelligent Airtime Scheduling
    . Ensures strict priority for video flows
    . Band Steered Admission Control
+  Smart Channel Selection in AP Mode
    . DFS(Dynamic Frequency Selection)
    . Automatic Channel Scanning to check interference
    . Fast channel changes with zero packet loss
Specification
+  ADSL2+, VDSL2 (Vplus/35b)
+  Antenna
    . 3x3 (2.4 GHz) + 4x4 (5 GHz)
+  Transmission Rate
    . 2.4GHz : 450Mbps (802.11 n , 40MHz)
    . 5GHz : 1.7Gbps (802.11ac, 160MHz/80MHz+80MHz)
+  Physical Interface
    . 4 Gigabit Ethernet Ports
    . 1 Gigabit WAN Port
    . USB 3.0 + USB 2.0 ports
    . WPS (Wi-Fi Protected Setup) Push Button
    . 1 A/VDSL port
    . 2 telephone ports(RJ11)
    . Reset Button
    . Power Switch
Accessories
+  Ethernet Cable
+  User Manual
+  Power Adaptor
+  DSL Filter W / Spiltter
