AR4010 (With VoIP)

Broadband CPE – AP Routers

AR4010 (With VoIP)

AR4010 (With VoIP)

802.11n/ac Dual band Gigabit AP Router for Seamless & Concurrent Wireless Video Streaming with VoIP
(2.4GHz 2x2 + 5GHz 2x2 (3x3 Optional))

AR4010 802.11n/ac Dual Band AP Router is designed for concurrent wireless HD video streaming without any interruptions at every corner of your home. With the cutting edge technologies such as beam-forming, spatial multiplexing, and STBC, AR4010 not only increases throughput but also extends Wi-Fi ranges revolutionary.

The concurrent dual-band WiFi makes speed of up to 300Mbps at 2.4GHz band and 900Mbps (1.3Gbps optional) at 5GHz band. It also supports voice calls through VoIP. Moreover, it is equipped with the advanced management protocols such as SNMP, TR-069, TR-098 as well as user friendly GUI for easy & cost saving management.

Product Map

INQUIRY

For more information, please click here

Click

Features & Differentiators
+  VoIP
   . 1FXS for analog phones and faxes
+  APR (Automatic Packet Recovery)
    . Recovers dropped packet by the Wi-Fi MAC layer
+  Green Router
    . Receiver Chain Power Saving
    . One touch WiFi On/Off Button
    . Adaptive CPU and Ethernet power saving
+  Intelligent Airtime Scheduling
    . Ensures strict priority for video flows
    . Band Steered Admission Control
+  Smart Channel Selection
    . DFS (Dynamic Frequency Selection)
    . Automatic Channel Scanning to check interference
    . Fast channel changes with zero packet loss
Specification
+  Standard Compliance:
     . IEEE 802.11b/g/n 2.4GHz
     . IEEE 802.11a/n/ac 5GHz
 +  Antenna
     . 2x2 (2.4GHz) + 2x2 (5GHz) (3X3 (5GHz, Opt))
 +  Transmission Rate
     . 2.4GHz : 300Mbps (802.11n , 40MHz)
     . 5GHz : 900Mbps (802.11ac, 80MHz) / 1.7Gbps (802.11ac, 80MHz, Opt)
 +  Physical Interface
     . 4 Gigabit Ethernet Ports
     . 1 Gigabit WAN Port
     . USB 2.0 Port
     . WPS (Wi-Fi Protected Setup) Push Button
     . 1 Telephone port (RJ11)
     . Reset Button
     . Power Jack
Accessories
+  Ethernet Cable
+  User Manual
+  Power Adaptor
Dimension
220mm x 160mm x 38mm
